ZF – ERGOPOWER 2 WG - 94 EC Repair Manual PDF

To your attention, we present the Repair Manual with the necessary information, helpful instruction for ZF – ERGOPOWER 2 WG - 94 EC. Electronic guide is written to support the maintenance, repair procedures, troubleshooting, and solve any problems.

TABLE OF CONTENTS:

Preface
General
Denomination of standard dimensions
Conversion table
Tightening torques for screws
Labeling of identification plate and information on spare parts ordering
Configuration of transmission
Measuring points and connections
Notes on oil grade and oil fill quantity

SPECIAL TOOLS
COMMERCIAL TOOLS

1. DISASSEMBLY
1.1 Removal of filter
2. DISASSEMBLY of proportional valves, inductive sensor, Hall sensor,
temperature sensor and breather
3. DISASSEMBLY of PTO
4. DISASSEMBLY of output flange
5. DISASSEMBLY of main pressure valve and converter safety valve
6. DISASSEMBLY of engine connection
7. REMOVAL of clutches and DISASSEMBLY of oil pressure pump
7.1 Removal of clutches
7.2 Disassembly of oil pressure pump
8. DISASSEMBLY of clutches
8.1 KV clutch
8.2 KR clutch
8.3 KA clutch
8.4 KB clutch
9. REASSEMBLY of clutches
9.1 KV clutch
9.2 KR clutch
9.3 KA clutch
9.4 KB clutch
10. REINSTALLATION of clutches and REASSEMBLY of oil pressure
pump
10.1 Oil pressure pump
11. REASSEMBLY of converter safety valve and main pressure valve
11.1 Reassembly of converter safety valve
11.2 Reassembly of main pressure valve (control pressure valve)
12. REASSEMBLY of output flange
13. Reassembly of PTO
14. REASSEMBLY of engine connection
15. REASSEMBLY of proportional valves, inductive sensor, Hall sensor,
temperature sensor, breather and screw plugs
16. REASSEMBLY of filter, closing components for oil filler and oil drain
plug

But it is important to pay attention to the safety section before use in order to avoid breakdowns and injuries. This guide helps beginners and experienced professionals.

Features of the Manual
Format: PDF
Language: English
Pages: 95
Compatible with all versions of Windows, Mac, Linux, iPhone, iPad, and Android
Factory file covers removal, reassembly, disassembly, many screenshots, diagrams, schemes, and other general material. Also, the tutorial supports the search function to view the entire manual and print the desired pages.
