Yale Truck B892 (MP20XD) PDF Technical Information

Factory manuals contain detailed information about the routine and preventive maintenance, troubleshooting, disassembly/assembly of components, adjustment procedures for following Yale models:

MP20X
MP20XV
MO20F
MS 12-15X
MP20XD
B892

Yale set of manuals allows us to detect and resolve problems arising and uncertainties. The service manuals are an indispensable tool when using, maintenance, and repair trucks YALE B892 (MP20XD). Service manuals contents information for repair and service, special instructions for maintenance, technical specifications, step by step instructions for operation and maintenance, technical service instructions for truck B892. Also, in this set of manuals, you will find troubleshooting information, safety precautions, diagrams and schemes, pictures with step by step descriptions and etc for help to prolong quality work Yale truck.

The information on PDF format, in English. For convenience, we recommend using Adobe PDF Reader to ensure the correct display of all graphics. You can easily print the desired text or image that will help your work.  Contact us to obtain additional information or assistance about the work with this set of manuals.

CONTENTS:

• 1. FRAME/DRIVE UNIT
  • COVERS
  • LABELS AND DECALS
  • BATTERY COMPARTMENT
  • STEERING (ELECTRIC)
  • CONTROL BOX (PROPORTIONAL)
  • DRIVE UNIT
  • STEERING CONTROL UNIT (S/N B892X01500C <=> S/N B892X01556D)
  • STEERING CONTROL UNIT (S/N B892D01557D =>)
  • ARTICULATED SHAFT (S/N B892X01500C <=> S/N B892X01558D)
  • ARTICULATED SHAFT (S/N B892X01559D =>)
  • ELECTROMAGNETIC BRAKE
  • TIE RODS
  • SUPPORTS AND CASTER WHEELS
  • CASTER WHEEL
  • TRACTION MOTOR
• 2. OPERATOR COMPARTMENT
  • OPERATOR PLATFORM (S/N B892X01500C <=> S/N B892X01569D)
  • OPERATOR PLATFORM (S/N B892X01570D =>)
  • SIDE GATES
• 3. ELECTRICAL SYSTEM
  • ELECTRONIC SYSTEM
  • POWER CABLES DIAGRAM
  • WIRE HARNESS DIAGRAM
• 4. LOAD WHEEL
  • LOAD WHEELS
  • LOAD WHEELS (TANDEM)
• 5. HYDRAULIC SYSTEM
  • DISTRIBUTOR
  • HYDRAULIC SYSTEM
  • HYDRAULIC HOSE AND FITTINGS
  • HYDRAULIC CYLINDER
• 6. MAST-TWO STAGE LIMITED FREE-LIFT
  • MAST 2 STAGE (HI VI)
  • FORK 2 STAGE (HI VI)
• 7. OPTIONS
