| Type of catalogue: | spare parts catalog |
| Make: | Sumitomo |
| Region: | WorldWide |
| Inclusive languages: |
English |
| Amount of disks: |
1 CD, 1 PDF, 139 pages |
| Availibility | Instant Download |
| OS: | Windows XP 32 bit, Windows 7 32 bit, Windows 7 64 bit, Windows 8/8.1 32 bit, Windows 8/8.1 64 bit, Windows 10 32 bit, Windows 10 64 bit, Windows 11 64 bit, Windows 11 Pro 64 bit |
| Price, USD: | 39 |
We invite you to familiarize yourself with this Parts Manual for the correct use, maintenance, and repair of the Sumitomo Hydraulic Excavator Diesel Engine 4LE2 Tier3 Type XYSS01, XYSS02 models.
Table of Contents
ENGINE GASKET KIT 83-51165-005
CYLINDER HEAD COVER 83-51165-010
CYLINDER HEAD 83-51165-011
CYLINDER BLOCK 83-51165-012
OIL PAN AND LEVEL GAUGE 83-51165-013
CAMSHAFT AND VALVE 83-51165-014
CRANKSHAFT, PISTON AND FLYWHEEL 83-51165-015
TIMING GEAR CASE AND FLYWHEEL HOUSING 83-51165-020
INLET MANIFOLD 83-51165-025
EXHAUST MANIFOLD 83-51165-027
WATER PUMP AND CORROSION RESISTOR 83-51165-030
THERMOSTAT AND HOUSING 83-51165-031
WATER PIPING; ENGINE 83-51165-032
FAN AND FAN BELT 83-51165-033
TURBOCHARGER SYSTEM 83-51165-036
FUEL INJECTION SYSTEM 83-51165-040
FUEL FILTER AND BRACKET 83-51165-041
OIL COOLER AND OIL FILTER 83-51165-050
OIL PUMP AND OIL STRAINER 83-51165-051
OIL AND VACUUM PIPING; ENGINE 83-51165-052
EMISSION PIPING 83-51165-057
ENGINE ELECTRICAL CONTROL PARTS 83-51165-060
STARTER 83-51165-065
GENERATOR 83-51165-066
INJECTION PUMP 83-51165-080
TIMING CHAIN CASE 83-51165-089
This guide helps beginners and experienced professionals in the use and maintenance of this equipment.
Features of the Manual
Format: PDF
Language: English
Pages: 139
Compatible with all versions of Windows, Mac, Linux, iPhone, iPad, and Android
All material in this electronic guide is divided into several sections with information about step-by-step instructions, settings, transmissions, many screenshots, diagrams, and schemes. The screenshots and diagrams will help you quickly and easily familiarize yourself with your forklift and understand all instructions in this tutorial.
