OM Pimespo DUAL15-3 Workshop Manual PDF

Presented for sale the Workshop Manual which has a collection of information with illustrations for OM Pimespo DUAL15-3. The electronic guide contains information about technical data, repair operations, safety rules, instructions, service, and maintenance procedures, diagrams, and schemes. All screenshots are rather detailed, therefore to work with the program easily.

Please! Pay special attention to the rules, and notes material. Failure to do so could result in personal injury or device damage. An online text comes in PDF format in English, German, French, Italy language. To work with the factory file, you need to install the application Adobe PDF Reader. In case of any questions - please write to us. We will provide after-sale support.

List of chapters:

Chapter 1: Vehicle data
Chapter 2: Drive motor
Chapter 3: Drive wheel
Chapter 4: Gear
Chapter 5: Brake
Chapter 6: Steering
Chapter 7: Mast
Chapter 8: Vehicle control system (FZS)
Chapter 9: Travel and pump controller (FPS)
Chapter 10: Operating console
Chapter 11: Load handling control (LHC)
Chapter 12: EM.-STOP and amplifier module (NAV)
Chapter 13: Distributor board
Chapter 14: Negative feeder module
Chapter 15: Main contactors
Chapter 16: DC/DC converter
Chapter 17: Distance sensor for main lift
Chapter 18: Distance sensor for additional lift
Chapter 19: Distance sensor for swivelling
Chapter 20: Distance sensor for side shifting
Chapter 21: SERVICE mode
Chapter 22: Teaching-in process
Chapter 23: Reference sequence
Chapter 24: Chassis valve block
Chapter 25: Attachment valve block
Chapter 26: Pump motor
Chapter 27: Hydraulic motor
Chapter 28: Pump
Chapter 29: Oil level indicator
Chapter 30: Ventilation filter
Chapter 31: Trilateral head TLH
Chapter 32: Lubrication plan
Chapter 33: Chains
Chapter 34: Inductive automatic steering
Chapter 35: Error codes
Chapter 36: Troubleshooting guide
Chapter 37: WINFLASH
Chapter 38: ParaDig 133 / ParaDig 153
Chapter 39: Telescopic fork
Chapter 40: Filling aid
Chapter 41: Converter (AC only)
Chapter 42: Panel
Chapter 43: EASS
Chapter 44: Individual driving settings
