New Holland LM6.32/35/LM7.35/42/LM9.35 Stage IIIB Telescopic Handler Manual PDF

The purpose of this New Holland service manual is to provide complete information about precisely, the rules of repair, maintenance, as well as use the telescopic handlers LM6.32, LM6.35, LM7.35, LM7.42, LM9.35 Stage IIIB. This manual contains information on diagnosis and testing, maintenance and repair using proven and effective methods, schemes and recommendations.

All information, including descriptions and specifications contained in this manual, has been prepared by specialists company New Holland and meets the highest requirements, so trust the specialists and be calm for your equipment with this manual. The guide is written in a convenient format for quickly finding the information you need. All these data will help ensure a reliable state of your equipment for years to come. This manual is specially prepared for the convenience and satisfaction of the needs of technicians and owners throughout the world. Therefore, it is very important to observe all the precautions that are written in this manual.

This factory manual is in PDF format. We recommend using application Adobe PDF Reader for the correct viewing of text, images, and diagrams. If you still have any questions that concern the work with this manual - contact us, we provide the after-sale support.

Models:
LM6.32
LM6.35
LM7.35
LM7.42
LM9.35

Contents:

• 1. Engine
  • Engine and crankcase
  • Fuel injection system
  • Air cleaners and lines
  • Intake and exhaust manifolds and muffler
  • Engine cooling system
  • Engine lubrication system
• 2. Transmission
  • Powershift transmission
  • Powershift transmission external controls
  • Powershift transmission internal components
  • Gearbox
  • Torque converter
• 3. Four-Wheel Drive (4WD) system
  • Driveshaft
• 4. Front axle system
  • Powered front axle
  • Front bevel gear set and differential
  • Final drive hub, steering knuckles, and shafts
• 5. Rear axle system
  • Powered rear axle
  • Rear bevel gear set and differential
• 6. Brakes and controls
  • Hydraulic service brakes
  • Parking brake or parking lock
  • Trailer brake hydraulic control
  • Front axle brake
• 7. Hydraulic systems
  • Hydraulic systems
  • Fixed displacement pump
  • Variable displacement pump
  • Main control valve
  • Pilot system
  • Auxiliary hydraulic function control
  • Hydraulic fan drive cooling system
  • Main lift system
  • Front loader arm hydraulic system
  • Boom hydraulic system
  • Tool quick coupler hydraulic system
  • Telescopic arm hydraulic system
• 8. Steering
  • Steering control
  • Hydraulic control components
  • Cylinders
• 9. Cab climate control
  • Ventilation
  • Air conditioning
• 10. Electrical systems
  • Harnesses and connectors
  • Engine starting system
  • Alternator
  • Fuel tank system
  • Cab controls
  • External lighting
  • Cab lighting
  • Warning indicators, alarms, and instruments
  • FAULT CODES
• 11. Telescopic single arm
  • Telescopic arm
• 12. Platform, cab, bodywork, and decals
  • Cab
