New Holland E485C Crawler Excavator PDF Service Manual

This New Hollan manual contains step by step recommendation, service, and technical information, schemes, troubleshooting data,  instructions and illustrations that will help prevent breakages crawler dozer E485C

 New Holland manual is important and indispensable source information for service workshop that is engaged in the repair and service of this equipment and also for people who wanted more understand this excavator and max use this equipment. This manual is systematics information and which contains all the necessary data and recommendation.

The manual is a factory file in PDF format, which contains scanning pages on English, any one of which we can be printed easily. We recommend using Adobe PDF Reader, to be sure all images/graphics will display correctly.

You can purchase this manual on our website in the easiest way - by clicking on the Buy now. Within a few minutes, you will receive an email with all the information on installation and use. If you have any questions - email us and we will help you.

Models:
E485C

CONTENTS:

• 1. Introduction
  • Safety rules
  • Personal safety
  • Torque
  • Basic instructions - Important notice regarding equipment servicing
  • Basic instructions - How to use the maintenance standard and precautions
  • Basic instructions - Preparation for performance tests
  • Basic instructions - Precaution for disassembly and assembly
  • Basic instructions - Installing hydraulic equipment
  • Basic instructions - Electrical equipment precautions
  • Capacities - Fluids and lubricants
  • Hydraulic contamination
  • Product identification
  • Product identification - Machine Orientation (front, right, rear, left) . . .
• 2. Engine
  • Engine and crankcase
  • Pan and covers
  • Valve drive and gears
  • Cylinder heads
  • Connecting rods and pistons
  • Crankshaft and flywheel
  • Pump drives
  • Fuel tanks
  • Lift pump and lines
  • Fuel filters
  • Fuel injection system
  • Air cleaners and lines
  • Turbocharger and lines
  • Intake and exhaust manifolds and muffler
  • Engine cooling system
  • Fan and drive
  • Engine lubrication system
  • Oil cooler and lines
  • Exhaust Gas Recirculation (EGR) - Diesel Particulate Filter (DPF) exhaust treatment
• 3. Hydraulic systems
  • Hydraulic systems
  • Reservoir, cooler, and filters
  • Variable displacement pump
  • Pump control valves
  • Main control valve
  • Hydraulic hand control
  • Hydraulic foot control
  • Hydraulic swing system
  • Hydraulic travel system
  • Boom hydraulic system
  • Dipper hydraulic system
  • Excavator and backhoe bucket hydraulic system
  • Hydraulic central joint
• 4. Frames and ballasting
  • Upper frame
  • Swing ring assembly
  • Ballasts and supports
• 5. Tracks and track suspension
  • Tracks
  • Track tension units
  • Track rollers
• 6. Cab climate control
  • Air conditioning
• 7. Electrical systems
  • Electrical system
  • Harnesses and connectors
  • Engine control system
  • Engine starting system
  • Alternator
  • Battery
  • Fuel injection system
  • Engine cooling system
  • Engine oil system
  • Electronic modules
  • Hydraulic system control
  • Cab Heating, Ventilation, and Air-Conditioning (HVAC) controls
  • Fault codes
• 8. Lubrication system
  • Grease lubrication system
  • Booms, dippers, and buckets
  • Boom
  • Bucket
• 9. Platform, cab, bodywork, and decals
  • Cab
  • Pneumatically-adjusted operator seat
  • Machine shields and guards
  • Fenders and guards
