New Holland Combine TC4.90 / TC5.70 / TC5.80 / TC5.90 Hillside Manual PDF

New Holland service manual is systematics information for the owners of the combine and which contains the data to diagnose and troubleshooting information for models TC4.90, TC5.70, TC5.80, TC5.90 this brand. The repair manual is important and indispensable source information for service workshop that is engaged in the repair and service of New Holland combines and also for people who wanted more understand these combines.

Series:
TC4.90
TC5.70
TC5.80
TC5.90
TC5.90 Hillside
TC4.90 FPT NEF 4 STAGE IV,
TC4.90 FPT NEF TIER 3,
TC5.70 FPT NEF 4 STAGE IV,
TC5.70 FPT NEF TIER 3,
TC5.80 FPT NEF 6 STAGE IV,
TC5.80 FPT NEF TIER 3,
TC5.90 FPT NEF 6 STAGE IV,
TC5.90 FPT NEF TIER 3,
TC5.90 Hillside FPT NEF 6 STAGE IV

Contents:

• INTRODUCTION
• ENGINE
  • Engine and crankcase
  • Engine air compressor
  • Selective Catalytic Reduction (SCR) exhaust treatment
  • Rotary screen
• TRANSMISSION
  • Mechanical transmission
  • Mechanical transmission external controls
  • Gearbox
  • Gearbox internal components
  • Differential
• FRONT AXLE SYSTEM
  • Final drives
• REAL AXLE SYSTEM
  • Powered rear axle
  • Non-powered rear axle
• HYDROSTATIC DRIVE
  • Transmission and steering hydrostatic control
  • Reservoir, cooler, and lines
  • Pump and motor components
  • Hydrostatic transmission
  • Rear hydrostatic transmission
• BRAKES and CONTROL
  • Hydraulic service brakes
  • Parking brake or parking lock.
• HYDRAULIC SYSTEM
  • Hydraulic systems
  • Reservoir, cooler, and filters
  • Variable displacement pump
  • Main control valve
  • Remote control valves
  • Machine leveling control system
  • Machine lateral leveling system
  • Machine longitudinal leveling system
  • Header or attachment leveling system
  • Reel control system
  • Header or attachment height system
• STEERING
  • Hydraulic control components
  • Steering control
  • Pump
  • Cylinders
• CAB CLIMATE CONTROL
  • Air conditioning
• ELECTRICAL SYSTEMS
  • Electrical system
  • Harnesses and connectors
  • Selective Catalytic Reduction (SCR) electrical system
  • Cab Heating, Ventilation, and Air-Conditioning (HVAC) controls
  • Heating, Ventilation, and Air-Conditioning (HVAC) control system
  • Sieve electric control
  • Harvest material flow control system
  • Reverser electric control
  • Leveling system electrical components
  • Fault Codes
• ATTACHMENTS / HEADERS
  • Attachment/Header reel
  • Belt feeding
• PRODUCT FEEDING
  • Feed roll
  • Feeder housing
  • Floating roll, feed chain, and drive
  •  Feeder drive system
  • Feeder reverse system
• THRESHING
  • Threshing
  • Drum
  • Drum/Rotor variator with electrical control
  • Concave
  • Concave control system
  • Threshing mechanism drive system
• SEPARATION
  • Beater
  • Straw walkers and shafts
• RESIDUE HANDLING
  • Straw chopper drive system
  • Straw chopper electro-magnetic clutch support
• CLEANING
  • Cleaning
  • Cleaning drive systems
  • Grain pan
  • Upper shaker shoe
  • Lower shaker shoe
  • Fan housing
  • Fan drive system
  • Tailings return system
• CROP STORAGE / UNLOADING
  • Grain tank unload
  • Clean grain elevator
• PLATFORM, CAB, BODYWORK, and DECALS
  • Machine shields and guards
  • Cab
  • Cab windshield and windows

If you want to better understand your combines get the maximum benefit from it, and also save time and money for maintenance and repair - we advise you to purchase this manual. This comprehensive manual is suitable for professional technicians and novice mechanics alike.

Features of the Manual
Format: PDF
Language: English
Pages: 4809
Compatible with all versions of Windows, Mac, Linux, iPhone, iPad, and Android
New Holland workshop manual contains detailed information about various systems, the process of assembly and disassembly, repair recommendations all electric components, and control units, step-by-step recommendations with pictures, parts diagrams, service instructions and etc.
