Manitou Gearbox T 12000 Repair Manual PDF

You have the chance to purchase this Electronic Repair Manual about Manitou Gearbox T 12000 model. Factory file includes step-by-step instructions, descriptions, settings, troubleshooting, operation, technical data, safety, and of course a lot of illustrations, different schemes, tables, and diagrams.

Please observe strictly the safety rules and notes, advice and other recommendations in this factory file to avoid any breakdowns, injuries, damage or malfunctions. The Online text comes in PDF format and includes 132 pages in French for reading. We recommend using Adobe PDF Reader, to be sure all images/graphics will display correctly.

Contents:

SUMMARY
T12000 GEARBOX
UNIT OPERATION
SECTIONAL VIEWS AND IDENTIFICATION OF PARTS
Gearbox casing and intermediate plate assembly Fig. AT
Converter assembly Fig. B
Forward/reverse and 1st/second clutch assembly Fig. VS
4th/3rd clutch assembly and output shaft Fig. D
Dual Modulation Valve Assembly Fig. E
Simple modulation valve assembly and mechanical inching Fig. F
Assembly instructions Fig. G,H,I,J,K
DISASSEMBLING THE GEARBOX 1
REASSEMBLING THE 60 GEARBOX
CLUTCH ENGAGEMENT - 3 SPEED GEARBOX 78
CLUTCH ENGAGEMENT - 4 AND 6 SPEED GEARBOX 79
INSTALLATION DRIVE DISC 80
"81 GEARBOX-ENGINE" INSTALLATION PROCEDURE
SPECIFICATIONS AND SERVICE DATA 82
VEHICLE MAINTENANCE AFTER GEARBOX OVERHAUL 83
PRESSURE CONTROL 84
CLEANING AND CHECK 86
PARKING BRAKE SERVICE 87
TROUBLESHOOTING 88
CONVERTER STALL PROCEDURE 89
DESCRIPTION
