MacDon D50-D65, FD70-FD75 Header with CA20-25 Combine Adapter

This instructional manual describes the unloading, set-up, and predelivery requirements for the MacDon FD75 FlexDraper with a CA25 Combine Adapter for North America. Electronic set includes general safety information, troubleshooting, all recommendation about this device, install, maintenance, unload and assembly instructions, also many helpful illustrations, diagrams with description, and schemes for MacDon FD75 FlexDraper with a CA25 Combine Adapter. Use the Table of Contents to guide you to specific areas. Retain this instruction for future reference.

Carefully read all the material provided before attempting to unload, assemble, or use the machine. Factory text comes in PDF format with many files that complete each other important information. In order to view, as well as print the necessary information - we recommend installing the Adobe PDF Reader program (or any analog of application that supports PDF files). Each page is available for printing. Сheck with us if you will have questions or need our help. Our managers will answer all your questions.

Models:
D50 and D60 Harvest Header
D65 Draper Header
FD70 FlexDraper
FD75 FlexDraper

Table of Contents:

INTRODUCTION
GENERAL SAFETY
RECOMMENDED TORQUES
CONVERSION CHART
STEP 1. UNLOAD HEADER
STEP 2. LOWER HEADER
STEP 3. REMOVE SHIPPING STANDS
STEP 4. INSTALL REEL LIFT CYLINDERS
STEP 5. RE-POSITION GEARBOX
STEP 6. INSTALL REEL SPEED SENSOR
STEP 7. INSTALL OPTIONS
STEP 8. SET UP ADAPTER
STEP 9. ATTACH TO COMBINE
STEP 10. CONNECT REEL TO FORE-AFT CYLINDERS
STEP 11. ATTACH CAM ARMS
STEP 12. INSTALL REEL END SHIELDS
STEP 13. REMOVE SHIPPING SUPPORTS
STEP 14. INSTALL CROP DIVIDERS
STEP 15. INSTALL HEADER END SHIELDS
STEP 16. POSITION TRANSPORT LIGHTS
STEP 17. PRE-DELIVERY INSPECTION
STEP 18. RUN-UP THE HEADER
STEP 19. POST-RUN-UP ADJUSTMENTS
