Kobelco SK480LC-6 Hydraulic Excavator with Mitsubishi diesel engine 6D2 PDF Manual

This manual provides instructions for troubleshooting and repairing the hydraulic excavator Kobelco SK480LC-6 with the Mitsubishi diesel engine 6D24 series. This manual is organized to guide a service technician through the logical steps of identifying and correcting problems related to the engine.

The workshop manual is organized to provide an easy flow from problem identification to problem correction. This manual provides general information, specifications, diagrams, and service tools, troubleshooting information. n this manual, you will find recommendations for repair, step by step instructions. It also will help you easily and readily find the fault location and quickly eliminate it, as well as help to make planned and unscheduled maintenance of this equipment.

Kobelco workshop manual is a file PDF, which contains 1260 pages, any one of which we can be printed easily. We recommend using Adobe PDF Reader, to be sure all images/graphics will display correctly. If you have any questions about this manual - write to us, and we will answer all your questions.

Model Excavator:
SK480LC-6

Applicable Engine models:
6D24
6D24-T
6D24-TC
6D24-TL

CONTENTS:
Cycle Times
Maintenance Specifications
Hydraulic Schematics
Pressure Adjustment
Mechatronics
Electrical Schematics
Specification section
Maintenance section
System section
Disassembly section
Troubleshooting
Engine section
Installation procedures for optional attachment
