Kobelco Excavator SK60V - SK220LCV Super Mark V PDF Handbook

A factory service handbook is designed as an assistant for servicing the hydraulic excavator SK60V - SK220LCV Super Mark V Kobelco. The handbook contains detailed diagnostic and repair information, troubleshooting information, charts and diagrams, installation instructions and much other necessary information.

The manual contains information about the systems, construction, operation, adjustment and service procedures, with diagrams for the hydraulic excavators Kobelco. This manual is organized into several sections, each section contents full thematic information (see below the content). Save your time and get recommendations for the correct maintenance and repair procedure of your excavator with this handbook.

The Kobelco handbook is a scanned copy factory manual and in PDF format on English. We recommend using Adobe PDF Reader, to be sure all images/graphics will display correctly. Working with this manual, you can easily copy, save, and print the information you need. If necessary, you can print all pages, pictures, charts completely. If you still have any questions that concern the work with this manual - contact us, we provide the after-sale support.

APPLICABLE:
SK60V - LE-20101~
SK100V - YW-07901~
SK100LV - LX-10201~
SK120V - LP-13601~
SK120LCV - YP-02501~
SK200V - YN-23301~
SK200LCV - YQ-02801~
SK220V - LQ-03701~
SK220LCV - LL-02501~

CONTENTS:
1. GENERAL DIMENSIONS
2. MACHINE SPECIFICATION TABLE
3. MAJOR SPECIFICATIONS
4. PERFORMANCE TABLE
5. WEIGHT OF COMPONENTS
6. CAPACITY TABLE OF LUBRICATION OIL AND COOLANT
7. LIST OF FILTER AND ELEMENT
8. SPECIFIED OIL, GREASE AND FILTER ELEMENT LIST
9. PROCEDURES FOR MEASURING
10. HYDRAULIC PUMP CONTROL CURVE
11. MECHATRO CONTROLLER
12. HYDRAULIC SYSTEM DIAGRAM
13. ELECTRIC CIRCUIT DIAGRAM
14. DIMENSIONS OF A IT ACHMENTS
15. MAINTENANCE STANDARD
16. WORKING RANGES OF ATTACHMENTS
17. LIFTING CAPACITY DIAGRAM
18. REFERENTIAL DATUM
19. TABLE OF CONVERSION RATE
