JCB Teletruks TLT 25G, TLT 30G Service Manual PDF

This PDF service manual is designed for repair, maintenance and troubleshoot JCB Teletruks TLT 25G, TLT 30G. This manual provides safety instructions for the operation, inspection, and maintenance of the JCB Teletruks. Failure to follow these instructions can result in serious injury or equipment damage.

The explanations, numerical data, pictures and illustrations given in this manual are based on the information available at the time of its publication.

This pdf manual explains how to operate the JCB Teletruks correctly. She gives directions for scheduled maintenance. All who work on the truck and service it should read and understand this manual. This is the only way to unleash the potential of the truck and ensure your safety.

The service repair manual is presented in PDF format. It does not require installation (INSTANT DOWNLOAD). Manual works with Adobe Acrobat Reader. If necessary, you can also print the service guide and use it as a service handbook.

Publication No. 9813/8800 - ISSUE 2

Models covered:
TLT 25G,
TLT 30G.

Contents:

• 01 - Machine
  • 01-03 Safety
  • 01-06 About this Manual
  • 01-09 Description
  • 01-33 Cleaning
• 03 - Attachments, Couplings, and Load Handling
  • 03-00 Attachments
  • 03-09 Lift Arm Quickhitch
  • 03-30 Shovel
  • 03-33 Fork
  • 03-88 Work Platform
• 06 - Body and Framework
  • 06-00 Body and Framework
  • 06-06 Moveable Panel and Cover
  • 06-12 Lift Arm
  • 06-30 Pivot Pins
  • 06-39 Carriage
  • 06-57 Counterweight
  • 06-63 Identification Label
  • 06-66 Tools
  • 06-69 Maintenance Strut
  • 06-75 Fire Extinguisher
  • 06-89 Window Guard
• 09 - Operator Station
  • 09-00 Operator Station
  • 09-09 Window
  • 09-12 Operator Seat
  • 09-15 Seat Belt
  • 09-18 Door
  • 09-27 Controls
  • 09-28 Cables and Fittings
  • 09-33 Safety Label/Chart
  • 09-36 Steering Wheel
  • 09-81 Mount
• 12 - Heating, Ventilating, and Air-Conditioning (HVAC)
  • 12-04 Heater Unit
• 15 - Engine
  • 15-00 Engine
  • 15-18 Engine Belt
  • 15-21 Oil Filter
  • 15-24 Air Filter
  • 15-72 Alternator
  • 15-75 Starter Motor
  • 15-81 Spark Plug
  • 15-87 Switch
• 18 - Fuel and Exhaust System
  • 18-01 LPG System
  • 18-03 Tank
  • 18-09 Filter
  • 18-24 Exhaust
  • 18-60 Carburettor
  • 18-63 Valve
  • 18-66 Vapouriser
• 21 - Cooling System
  • 21-00 Cooling System
  • 21-03 Cooling Pack
  • 21-06 Expansion Tank
  • 21-93 Hose
• 24 - Brake System
  • 24-00 Brake System
  • 24-03 Service Brake
  • 24-18 Park Brake
• 25 - Steering System
  • 25-00 Steering System
  • 25-01 Pump
  • 25-06 Steer Unit/Valve
  • 25-12 Column
  • 25-18 Front Track Rod
• 27 - Driveline
  • 27-00 Driveline
  • 27-20 Axle
  • 27-27 Hub
  • 27-29 Wheel
  • 27-31 Wheel Drive Pump
  • 27-32 Wheel Drive Motor
  • 27-32-00 General
  • 27-33 Tyre
• 30 - Hydraulic System
  • 30-00 General
  • 30-03 Tank
  • 30-04 Filter
  • 30-12 Variable Displacement Pump
  • 30-15 Cylinder / Ram
  • 30-51 Lift Arm Control Valve Block
  • 30-60 Directional Control Valve
  • 30-93 Hose
  • 30-97 Connectors
• 33 - Electrical System
  • 33-00 Electrical System
  • 33-03 Battery
  • 33-09 Power Distribution
  • 33-12 Harness
  • 33-15 Alarm
  • 33-24 Instruments
  • 33-27 Interior Switch
  • 33-40 Bulb
  • 33-45 Control Module
  • 33-54 Window Washer/Wipe
  • 33-57 Electronic Diagnostic
  • 33-66 Load Motion Control System
  • 33-84 Sensor
  • 33-86 Solenoid
• 72 - Fasteners and Fixings
  • 72-00 Fasteners and Fixings
  • 72-03 Screws
  • 72-06 Bolts
  • 72-18 Bearings
  • 72-21 Clips
  • 72-36 Threaded Insert
• 75 - Consumable Products
  • 75-00 Consumable Products
  • 75-03 Oil
  • 75-06 Grease
  • 75-09 Fluids
  • 75-10 Locking Fluids
  • 75-14 Solvents and Primers
  • 75-15 Adhesive
  • 75-16 Sealant
• 78 - After Sales
  • 78-24 Maintenance Schedules
  • 78-81 Clothing and Personal Protective Equipment (PPE)
  • 78-93 Special Tools
  • 78-96 Units of Measurement
