Hyundai Crawler Excavator R360LC-3 Service Manual PDF

This Hyundai guide includes workshop repair and maintenance instructions, wiring electrical and hydraulic diagrams, circuits and harness, etc. The pdf service manual is a system of assistance in the operation and repair of Hyundai crawler excavators, which allows troubleshooting computer systems.

Models covered:
R360LC-3

Contents:
Section 1 - General
Group 1 - Safety Hints
Group 2 - Specifications

Section 2 - Structure
Group 1 - Pump Device
Group 2 - Main Control Valve
Group 3 - Swing Device
Group 4 - Travel Device
Group 5 - RCV Lever
Group 6 - RCV Pedal

Section 3 - Hydraulic System
Group 1 - Hydraulic Circuit
Group 2 - Main Circuit
Group 3 - Pilot Circuit
Group 4 - Single Operation
Group 5 - Combined Operation

Section 4 - Electrical System
Group 1 - Component Location
Group 2 - Electrical Circuit
Group 3 - Monitoring System
Group 4 - Electrical Component Specification
Group 5 - Connectors

Section 5 - Mechatronics System
Group 1 - Outline
Group 2 - Mode Selection System
Group 3 - Automatic Deceleration System
Group 4 - Engine Speed Up / Down Function
Group 5 - Power Boost System
Group 6 - Engine Speed Sensing Function
Group 7 - Battery Charge Warning Function
Group 8 - Travel Control System
Group 9 - Hydraulic Oil Temp Warming Function
Group 10 - Automatic Warming Up Function
Group 11 - Engine Overheat Prevention Function
Group 12 - Self-Diagnostic Display System
Group 13 - Engine Control System
Group 14 - EPPR (Electro Proportional Pressure Reducing) Valve
Group 15 - Prolix Switch

Section 6 - Troubleshooting
Group 1 - Hydraulic and Mechanical System
Group 2 - Electrical System
Group 3 - Mechatronics System

Section 7 - Maintenance Standard
Group 1 - Operating Performance Test
Group 2 - Major Components
Group 3 - Track and Work Equipment

Section 8 - Disassembly and Assembly
Group 1 - Precaution
Group 2 - Tightening Torque
Group 3 - Pump Device
Group 4 - Main Control Valve
Group 5 - Swing Device
Group 6 - Travel Device
Group 7 - RCV Lever
Group 8 - Turning Joint
Group 9 - Boom, Arm, Bucket Cylinder
Group 10 - Undercarriage
Group 11 - Work Equipment

This comprehensive manual is suitable for professional technicians and novice mechanics alike.

Features of the Manual
Format: PDF
Language: English
Compatible with all versions of Windows, Mac, Linux, iPhone, iPad, and Android
This PDF Service Manual includes repair and troubleshooting information, technical service instructions, description of all repair and service procedures for the Hyundai Crawler Excavator R360LC-3 Model.
