Hyundai Crawler Excavator R180LC-7 Service Manual PDF

This PDF Service Manual includes detailed repair instructions, special fitting instructions, detailed diagrams, charts and circuits, additional service information for the Hyundai Crawler Excavator R180LC-7 Model.

This service manual contains technical information, step-by-step instructions, and customer service for crawler excavators Hyundai, technical specifications. Also, this guide contains clear technical information about the product and helps to identify existing and potential problems, perform maintenance and repair problem areas, and equipment problems.

This technical guide allows you to save time for searching for necessary repair information, guidelines for their assembly and installation, maintenance, and repair. It is a detailed source of important information on Hyundai Crawler Excavators, which helps to improve the maintenance and repair.

For your convenience, we present you with a link 'Hyundai pdf manual instant preview' on the top of this page. This link will help you to preview this PDF manual and understand whether this manual contains needed for your service information or not.

Models covered:
R180LC-7

Contents:
Section 1 - General
Group 1 - Safety Hints
Group 2 - Specifications

Section 2 - Structure and Function
Group 1 - Pump Device
Group 2 - Main Control Valve
Group 3 - Swing Device
Group 4 - Travel Motor
Group 5 - RCV Lever
Group 6 - RCV Pedal

Section 3 - Hydraulic System
Group 1 - Hydraulic Circuit
Group 2 - Main Circuit
Group 3 - Pilot Circuit
Group 4 - Single Operation
Group 5 - Combined Operation

Section 4 - Electrical System
Group 1 - Component Location
Group 2 - Electrical Circuit
Group 3 - Electrical Component Specification
Group 4 - Connectors

Section 5 - Mechatronics System
Group 1 - Outline
Group 2 - Mode Selection System
Group 3 - Automatic Deceleration System
Group 4 - Engine Speed Up / Down Function
Group 5 - Power Boost System
Group 6 - Engine Speed Sensing Function
Group 7 - Battery Charge Warming Function
Group 8 - Travel Speed Control System
Group 9 - Arm Half Flow System
Group 10 - Hydraulic Oil Temp Warming Function
Group 11 - Automatic Warming Up Function
Group 12 - Engine Overheat Prevention Function
Group 13 - Self Diagnostic Display System
Group 14 - Engine Control System
Group 15 - EPPR (Electro Proportional Pressure Reducing) Valve
Group 16 - Prolix Switch
Group 17 - Hyper Dat (Option)

Section 6 - Troubleshooting
Group 1 - Before Troubleshooting
Group 2 - Hydraulic and Mechanical System
Group 3 - Electrical System (up to #0138)
Group 4 - Mechatronics System (up to #0138)
Group 5 - Electrical System By Hyper Dat
Group 6 - Mechatronics System By Hyper Dat
Group 7 - Electrical System (#139 and up)
Group 8 - Mechatronics System (#139 and up)

Section 7 - Maintenance Standard
Group 1 - Operating Performance Test
Group 2 - Major Components
Group 3 - Track and Work Equipment

Section 8 - Disassembly and Assembly
Group 1 - Precaution
Group 2 - Tightening Torque
Group 3 - Pump Device
Group 4 - Main Control Valve
Group 5 - Swing Device
Group 6 - Travel Device
Group 7 - RCV Lever
Group 8 - Turning Joint
Group 9 - Boom, Arm, Bucket Cylinder
Group 10 - Undercarriage
Group 11 - Work Equipment
