Hitachi Wheel Loader ZW370-5B Workshop Manual PDF

[02/2014]


Type of catalogue:	repair manual
Make:	Hitachi
Region:	WorldWide
Inclusive languages:	English
Amount of disks:	1 CD, PDF file, 689 pages
Availibility	Instant Download
OS:	Windows XP 32 bit, Windows 7 32 bit, Windows 7 64 bit, Windows 8/8.1 32 bit, Windows 8/8.1 64 bit, Windows 10 32 bit, Windows 10 64 bit, Windows 11 64 bit
Price, USD:	40

Hitachi pdf manual instant preview

Note: You may also be interested in the following PDF manuals for the Hitachi Wheel Loader ZW 370-5B:
Technical Manual (Operational Principle)
Technical Manual (Troubleshooting)

This PDF Workshop Manual contains detailed information on repair and adjustment, control systems of the Hitachi Wheel Loader ZW370-5B.

The technical repair manual provides detailed illustrations, drawings, and electrical diagrams (wiring diagrams) of the Hitachi Wheel Loader ZW370-5B.

The pdf manual can be used in the repair of elements of the brake system, steering, electrical equipment, gearboxes, and all loader systems. Possible malfunctions and methods for their elimination, the mating dimensions of the main parts and the limits of their permissible wear, recommended lubricants and working fluids are given. The technical service manual also gives detailed recommendations for the maintenance of the loader of the specified model.

This technical service manual includes technical service information needed for routine maintenance and the current repair of the Hitachi Wheel Loader ZW370-5B. This pdf instruction covers tools and devices needed for maintenance and repair, maintenance standards, and removal/installation and assembles/ disassemble procedures.

This book will be very useful to all current and future owners of Hitachi loaders, and will also be able to provide the necessary technical assistance to mechanics, specialists of service stations, repair shops, and numerous services.

Document Part No. WNHE-EN-00

Models covered:
ZW 370-5B

CONTENTS:

SECTION 1 GENERAL
- Group 1 Precautions for Disassembling and Assembling
- Group 2 Tightening
- Group 3 Painting
- Group 4 Bleeding Air
- Group 5 Pressure Release Procedure
- Group 6 Preparation
SECTION 2 MAINTENANCE STANDARD
- Group 1 Body
- Group 2 Front Attachment
SECTION 3 BODY
- Group 1 Cab
- Group 2 Counterweight
- Group 3 Center Hinge
- Group 4 Engine
- Group 5 Radiator Assembly
- Group 6 Hydraulic Oil Tank
- Group 7 Fuel Tank
- Group 8 Pump Device
- Group 9 Control Valve
- Group 10 Pilot Valve
- Group 11 Unloader Valve
- Group 12 Combination Valve
- Group 14 Flow Regulator Valve
- Group 15 Cooling Fan System
- Group 16 Exhaust Filter
- Group 17 Ride Control Valve and Accumulator
- Group 18 Battery Disconnect Switch
SECTION 4 TRAVEL SYSTEM
- Group 1 Tire
- Group 2 Drive Unit
- Group 3 Axle
- Group 4 Propeller Shaft
- Group 5 Brake Valve
- Group 6 Steering Pilot Valve
- Group 7 Steering Valve
- Group 8 Steering Cylinder
- Group 9 Secondary Steering Device
- Group 10 Reducing Valve
- Group 11 Stop Valve
- Group 12 Main Pressure Block
- Group 13 Priority Hammer Valve and Shuttle Valve
- Group 14 Check Valve
SECTION 5 FRONT ATTACHMENT
- Group 1 Front Attachment
- Group 2 Cylinder

Screenshots for Hitachi Wheel Loader ZW370-5B Workshop Manual PDF:
