Hitachi Excavator Zaxis 450-3/500-3 Performance Check Troubleshooting PDF

For complete service information also see:
Training Text (Operational Principle)
Training Text (Operation)
Training Text (Maintenance)

This PDF Training Text (Performance Check Troubleshooting) contains detailed repair and maintenance information, illustrations and diagrams, special instructions, and other service information for Hitachi Excavators Zaxis 450-3/500-3 Models.

This technical manual provides detailed descriptions of typical faults, methods of their elimination, details of repair and adjustment mechanisms, electrical systems, and information on diagnosis and adjustment.

This technical repair manual comes in PDF format. So, it doesn't require any installation (Instant Download). We recommend you to use the application Adobe Acrobat Reader for working with PDF instructions. This application will allow you to search for necessary information using the search function, view information, copy, select, and print any page, chart, or image. PDF documents can be read on all devices. That includes iPhones, Android smartphones, tablets, and desktop and laptop computers that run Windows software as well as the macOS operating system.

Models covered:
Zaxis 450-3,
Zaxis 500-3.

Part No. TTLA-0672-ZX

CONTENTS:
SECTION 4 OPERATIONAL PERFORMANCE TEST
Group 1 Introduction
Group 2 Standard
Group 3 Engine Test
Group 4 Excavator Test
SECTION 5 TROUBLESHOOTING
Group 1 Diagnosing Procedure
Group 2 Monitor Unit
Group 3 Dr. ZX
Group 4 ICF
Group 5 Component Layout
Group 6 Troubleshooting A
Group 7 Troubleshooting B
Group 8 Electrical System Inspection
