Hitachi EX200(LC)-5 EX220(LC)-5 EX230LC-5 EX270(LC)-5 (Troubleshooting) Technical Manual TT157E-02

Technical manual (Troubleshooting) is intended for serving and troubleshooting Hitachi excavators EX200-5, EX200LC-5, EX220-5, EX220LC-5, EX230LC-5, EX270-5, EX270LC-5.
This manual includes special instructions, illustrations, diagrams, troubleshooting information, etc.
This technical manual is a system of assistance in the troubleshooting and repairing of Hitachi excavators, which allows to detect and resolve problems arising and uncertainties.
The technical manual comes in PDF format and includes 258 pages, which are printable. We recommend using Adobe PDF Reader, to be sure all images/graphics will display correctly.

Models covers:
EX200-5,
EX200LC-5,
EX220-5,
EX220LC-5,
EX230LC-5,
EX270-5,
EX270LC-5.

SECTION AND GROUP CONTENTS:
SECTION 4 OPERATIONAL PERFORMANCE TEST
Group 1 Introduction
Group 2 Engine Test
Group 3 Excavator Test
Group 4 Component Test
Group 5 Standard
SECTION 5 TROUBLESHOOTING
Group 1 Diagnosing Procedure
Group 2 Component Layout
Group 3 Troubleshooting A
Group 4 Troubleshooting B
Group 5 Troubleshooting C
Group 6 Electrical System Inspection
Group 7 Harness Check
