Fiat Kobelco E165, E195 Evolution Crawler Excavator Workshop Manual PDF

This workshop manual contains detailed service information, special instructions, technical specifications, diagrams and charts for Fiat Kobelco Crawler Excavators E165, E195 Evolution.
Workshop manual is a system of care in the serve and repair of Fiat Kobelco Crawler Excavators, that allows to identify and solve problems and inaccuracies.
This workshop manual comes in PDF format. We recommend using Adobe PDF Reader, to be sure all images/graphics will display correctly. If necessary, you can print the entire document or selected partitions.

Models covered:
E165 Evolution,
E195 Evolution.

INDEX:

• SAFETY PRECAUTIONS
  • Section 1 GENERALITIES
  • Section 2 SAFETY PRECAUTIONS
  • Section 3 SAFETY PLATES
• OPERATIONAL PRINCIPLE
  • Section 1 GENERAL
  • Group 1 Specifications
  • Group 2 Component Layout
  • Section 2 SYSTEM
  • Group 1 Mechatro Control System
  • Group 2 Mechatro Controller
  • Group 3 Hydraulic System
  • Group 4 Electrical System
  • Section 3 COMPONENT OPERATION
  • Group 1 Hydraulic Pump Assy
  • Group 2 Pilot Valve
  • Group 3 Control Valve
  • Group 4 Swing Device
  • Group 5 Travel Device
  • Group 6 Swivel Joint
  • Group 7 Cylinders
  • Group 8 Air Conditioner
• OPERATIONAL PERFORMANCE TEST
  • Section 4 OPERATIONAL PERFORMANCE TEST
  • Group 1 Introduction
  • Group 2 Standard Performances
  • Group 3 Test Procedures
  • Group 4 Mechatro Controller Adjustment
• TROUBLESHOOTING
  • Section 5 TROUBLESHOOTING
  • Group 1 Mechatro Control
  • Group 2 Hydraulic System
  • Group 3 Electrical System
• REPAIR INSTRUCTIONS
  • Section 1 GENERAL INFORMATION
  • Group 1 Precautions for Disassembly and Assembly
  • Group 2 Tightening Torque
  • Section 2 UPPERSTRUCTURE
  • Group 1 Cab
  • Group 2 Air Conditioner
  • Group 3 Counterweight
  • Group 4 Main Frame
  • Group 5 Pump Device
  • Group 6 Control Valve
  • Group 7 Swing Device
  • Group 8 Pilot Valve
  • Group 9 Solenoid Valve Unit
  • Section 3 UNDERCARRIAGE
  • Group 1 Swing Bearing
  • Group 2 Travel Device
  • Group 3 Swivel Joint
  • Group 4 Track Adjuster
  • Group 5 Front Idler
  • Group 6 Upper and Lower Roller
  • Group 7 Tracks
  • Group 8 Sprocket
  • Section 4 FRONT ATTACHMENT
  • Group 1 Front Attachment
  • Group 2 Cylinders
