Clark GTS 20/25/30/33 L (PSI 4G64) Service Manual

This service manual is designed for the maintenance, troubleshooting, repair, and overhaul of Clark GTS 20 L, GTS 25 L, GTS 30 L, and GTS 33 L forklifts equipped with the PSI 4G64 LPG engine.

Whether you are performing routine servicing or diagnosing a more complex mechanical, hydraulic, electrical, or transmission-related issue, this manual provides the information needed to complete the job correctly. The publication contains detailed service procedures, technical specifications, illustrations, schematics, and component diagrams prepared for technicians, workshop personnel, and equipment owners.

Clear explanations and step-by-step repair instructions are supported by detailed drawings and service illustrations, making it easier to identify components, understand system operation, and follow recommended repair procedures.

With comprehensive factory service information available at your fingertips, many inspection, maintenance, and repair tasks can be completed without unnecessary downtime. This makes the manual a valuable reference for keeping your forklift operating safely and efficiently.

The manual is supplied in PDF format and contains 769 pages. Individual pages or complete sections can be printed as required. For the best viewing experience, Adobe Acrobat Reader or a compatible PDF application is recommended.

Item Details

• Manufacturer: Clark
• Model Series: GTS L Series
• Models Covered:
  • GTS 20 L
  • GTS 25 L
  • GTS 30 L
  • GTS 33 L
• Engine: PSI 4G64 LPG
• Rated Capacity: 2000–3300 kg
• Manual Type: Service Manual
• Publication Number: SM 1024 (Rev. 1.3)
• Part Number: 8129703
• Publication Date: March 2017
• Format: PDF
• Pages: 769
• Language: English
