CASE tractors FARMALL 110A & 130A PDF Operation manual

This manual includes complete material on use, service, and repair for the tractors Case 110 A and 130 A. The operating manual contains the necessary sections with technical information, recommendations for troubleshooting, specifications, adjustment rules, instructions for use, maintenance and quality repairs, a safety section, various photographs, many diagrams and tables, and others.

We advise you to read this manual carefully before using it and pay special attention to the “safety rules” section to avoid any problem (breakage, damage, injury, or malfunction).

To view the material, you need to install Adobe PDF Reader, because this manual is in PDF format and contains 240 pages. With this application, you can easily copy, save and print the information you need. Contact us if you have questions or need our help. Our managers will answer all your questions.

Models:
Farmall 110A
Farmall 130A

Contents:

• 1 GENERAL INFORMATION
  • Note to the Owner
  • Part identification
  • Product identification
  • Ecology and environment
  • Run-in period of a new machine
  • Universal symbols
  • Noise levels
• 2 SAFETY INFORMATION
  • Safety rules
  • Roll over protective struture (ROPS)
  • Safety rules
  • Safety Decals - Cab models
  • Safety Decals – Models without cab
  • Before operating the tractor
  • Driving the vehicle
  • Operating the machine
  • Power take off (PTO) operation
  • Maintenance
  • Diesel fuel
  • Fire or explosion prevention
  • Intended use statement
• 3 CONTROLS AND INSTRUMENTS
  • Access to operator's platform
  • Operator's seat
  • Instructional seat
  • Forward controls
  • Left-hand side controls
  • Right-hand side controls
  • Rearward controls
  • Instrument panel
• 4 OPERATING INSTRUCTIONS
  • Commissioning the unit
  • Starting the unit
  • Stopping the unit
  • Moving the unit
• 5 TRANSPORT OPERATIONS
  • Preparing for road transport
  • Recovery transport
• 6 WORKING OPERATIONS
  • GENERAL INFORMATION
  • TRANSMISSION
  • POWER TAKE OFF (PTO)
  • HYDRAULICS
  • HYDRAULIC REMOTE CONTROL VALVES
  • THREE-POINT HITCH
  • Tractor drawbar
  • WHEEL TRACK ADJUSTMENT
  • BALLASTING AND TIRES
  • AUXILIARY POWER CONNECTIONS
• 7 MAINTENANCE
  • General information
  • Maintenance planning
  • WHEN THE WARNING LAMP LIGHTS
  • EVERY 10 HOURS OR DAILY SERVICE
  • FIRST 50 HOURS
  • EVERY 50 HOURS
  • EVERY 300 HOURS
  • EVERY 600 HOURS
  • EVERY 1200 HOURS OR ANNUALLY
  • EVERY 4000 HOURS OR 4 YEARS
  • GENERAL MAINTENANCE
  • Storage
• 8 TROUBLESHOOTING
  • Symptom(s)
• 9 SPECIFICATIONS
  • Machine overall dimensions – Models without cab
  • Machine overall dimensions – Cab models
  • Weight from the machine
  • Fluids and lubricants
  • Motor
  • Drive
  • Power Take-Off (PTO)
  • Steering
  • Hydraulics
  • Three-point hitch
  • Brakes
  • Electrical
  • Radio (if equipped)
