Case Pivot-Transport Planter 1200 series PDF Operator Manual

The Case manual contains important information about the safe operation, adjustment, and maintenance of your 12 or 16 Row, 12/23 or 16/31 or 24 Row 20 1200 Pivot-Transport planter.

All this factory information is a system supporting the operations and maintenance of planters, which enables us to detect and eliminate problems and inaccuracies. This is the same type of manual used by professional mechanics containing step by step instructions and highly detailed exploded diagrams and pictures to show how to complete every correctly or repair procedure.

The factory manufacturer and our site do not recommend to operate or permit anyone to operate or service this equipment until you or the other persons have read this manual. Unauthorized use or repair may cause serious injury.  So buy and read all this necessary information before you want to use or maintain this equipment.

This manual in PDF format on English. For work with this manual, you need to installer the application Adobe PDF Reader. You can print all this information, and we recommend that you store it in the glove compartment for reference during fieldwork. Contact you with our manager to obtain additional manuals or and any further information or assistance about your machine.

1200 Planter Overview:
12 Row Narrow Trailing
16 Row Narrow Trailing
12/23 Split Row Trailing
16/31 Split Row Trailing
24 Row 20 Trailing

CONTENTS:

• 1. TO THE OWNER.
  • AFS CONTROLLED & HYDRAULICALLY DRIVEN PLANTING SYSTEM
• 2. SAFETY/DECALS
  • SAFETY
  • TRANSPORT CYLINDER SAFETY STOPS
  • STORAGE AND SERVICE WING LOCK
  • PLANTER LATCHING AREAS
  • SAFETY DECALS
  • TRANSPORTING ON PUBLIC ROADS
  • TRANSPORTING THE PLANTER ON A FLATBED TRAILER
• 3. TRACTOR/PLANTER PREPARATION
  • TRACTOR REQUIREMENTS
  • 12 and 16 Row Planters
  • 12/23 and 16/31 Split Row Planters
  • 24 Row 20 Planters
  • DRAWBAR CONNECTION AND ADJUSTMENT
  • Swing Drawbar (If equipped)
  • Drawbar Assist
  • Universal Drawbar Helper
  • Hitch Pin and Safety Chain
  • Jack Stand
  • HYDRAULIC CONNECTIONS
  • 12 and 16 Row Planters
  • 12/23 and 16/31 Row Planters
  • 24 Row 20 Planters
  • MOTOR CASE DRAIN KITS
  • 22 GPM PTO PUMP SYSTEM
  • 36 GPM PTO PUMP
  • ELECTRICAL CONNECTIONS
  • PREPARING TO LEVEL THE PLANTER
  • TOOLBAR LEVELING - FRONT TO REAR
  • TOOLBAR HEIGHT
  • TOOLBAR LEVELING - SIDE TO SIDE
• 4. LUBRICATION/MAINTENANCE
  • ENVIRONMENT
  • PLASTIC AND RESIN PARTS
  • PLANTER CHECKS AND MAINTENANCE
  • SERVICE CHART
• 5. AS REQUIRED MAINTENANCE
  • ADVANCED SEED METER
  • SEED SENSOR AND SEED TUBE
  • PLANTING TOOLS
  • DEPTH CONTROL
  • ROW UNIT
  • SENSOR ADJUSTMENT
  • VACUUM SYSTEM
  • BULK HOPPER SYSTEM
  • HOSE CARRIER
  • BLEEDING HYDRAULIC CIRCUITS
• 6. FIELD OPERATION
  • PLANTER RAISING AND LOWERING
  • HOSE CARRIER FOLDING DURING PLANTER PIVOTING
  • PLANTING WITH HYDRAULIC DRIVE PLANTERS
  • ROW UNIT OPERATION
  • SEED METER FIELD OPERATION
  • ROW UNIT AND SEED METER DRIVE
• 7. MARKER ADJUSTMENT AND OPERATION
  • MARKER ADJUSTMENT (IF EQUIPPED)
  • MARKER OPERATION (IF EQUIPPED)
• 8. ROW UNIT ATTACHMENTS
  • ROW UNIT ATTACHMENTS
• 9. GRANULAR CHEMICAL COMPONENTS AND APPLICATION
  • GRANULAR CHEMICAL COMPONENTS (IF EQUIPPED)
• 10. BULK HOPPER SYSTEM
  • BULK HOPPER SYSTEM (IF EQUIPPED)
• 11. SPLIT ROW PLANTERS
  • 12/23 AND 16/31 SPLIT ROW PLANTERS
• 12. 24 ROW 20 PLANTERS
  • 24 ROW 20 PLANTERS
• 13. LIQUID FERTILIZER COMPONENTS AND APPLICATION
  • LIQUID FERTILIZER ATTACHMENT (IF EQUIPPED)
  • ORIFICE/INJECTOR SELECTION
  • INJECTOR TABLES
  • ORIFICE TABLES
  • LIQUID FERTILIZER ATTACHMENTS
• 14. SEED METER, VACUUM AND BULK HOPPER SETTINGS
  • RECOMMENDED SETTINGS
• 15. MACHINE STORAGE
  • PLANTER STORAGE PREPARATION
• 16. CROP CHANGEOVER
  • CROP CHANGEOVER
  • CROP CHANGEOVER CHECKLIST
• 17. TROUBLESHOOTING
  • PROBLEMS AND THEIR PROBABLE CAUSES
• 18. HYDRAULICS AND ELECTRICAL
  • PLANTER HYDRAULIC SCHEMATICS AND VALVE BLOCKS
  • ELECTRONICS COMPARTMENT
  • PLANTER HARNESS DIAGRAMS
  • FUSE IDENTIFICATION
  • FARMING SYSTEM HARNESSES
• 19. SPECIFICATIONS
  • PLANTER SPECIFICATIONS – 12 AND 16 ROW PLANTERS
  • SPECIFICATIONS – 12/23 AND 16/31 SPLIT ROW PLANTERS
  • SPECIFICATIONS – 24 ROW 20 PLANTERS
  • SPECIAL TORQUES
  • MAINTENANCE ACCESSORIES
  • FASTENER TORQUE CHART
  • STANDARD TORQUE DATA FOR HYDRAULIC TUBES AND FITTINGS
• DETAIL INDEX
