CASE Farmall 110A/120A/130A PDF Operation manual

The manual contains step-by-step advice, technical information, diagrams, troubleshooting information, instructions and illustrations to help prevent breakdowns and extend the life of your Case Farmall 110A / 120A / 130A tractors.

The instruction is provided in PDF format and includes 246 pages. All pages are available for printing. Before starting to operate the tractor, we recommend that you read this manual, it has a simple and convenient interface in English.

To buy the manual, click the Buy Now button, fill out the form and you will receive a download link in no time.

Models:
FARMALL 110A
FARMALL 120A
FARMALL 130A

Contents:

• 1 GENERAL INFORMATION
  • NOTE TO THE OWNER
  • Engine identification
  • Product identification plate
  • Ecology and the environment
  • Run in period of a new machine
  • International symbols
  • Noise levels
• 2 SAFETY INFORMATION
  • Safety rules
  • Roll - over protective structure (ROPS)
  • Safety rules
  • Safety decals - Cab models
  • Safety decals – Models without cab
  • Before operating the tractor
  • Driving the vehicle
  • Machine operation
  • Power Take-Off (PTO) operation
  • Servicing
  • Diesel fuel
  • Fire or explosion prevention
  • Intended use statement
• 3 CONTROLS AND INSTRUMENTS
  • ACCESS TO OPERATOR'S PLATFORM
  • OPERATOR'S SEAT
  • INSTRUCTOR'S SEAT
  • FORWARD CONTROLS
  • LEFT-HAND SIDE CONTROLS
  • RIGHT-HAND SIDE CONTROLS
  • REARWARD CONTROLS
  • Instrument panel
• 4 OPERATING INSTRUCTIONS
  • COMMISSIONING THE UNIT
  • STARTING THE UNIT
  • STOPPING THE UNIT
  • MOVING THE UNIT
• 5 TRANSPORT OPERATIONS
  • PREPARING FOR ROAD TRANSPORT
  • RECOVERY TRANSPORT
• 6 WORKING OPERATIONS
  • GENERAL INFORMATION
  • TRANSMISSION
  • POWER TAKE OFF (PTO)
  • HYDRAULICS
  • HYDRAULIC REMOTE CONTROL VALVES
  • THREE-POINT HITCH
  • Tractor drawbar
  • WHEEL TRACK ADJUSTMENT
  • BALLASTING AND TIRES
  • AUXILIARY POWER CONNECTIONS
• 7 MAINTENANCE
  • GENERAL INFORMATION
  • MAINTENANCE CHART
  • WHEN THE WARNING LAMP LIGHTS
  • EVERY 10 HOURS OR DAILY SERVICE
  • FIRST 50 HOURS
  • EVERY 50 HOURS
  • EVERY 300 HOURS
  • EVERY 600 HOURS
  • EVERY 1200 HOURS OR ANNUALLY
  • EVERY 1200 HOURS OR EVERY 2 YEARS
  • GENERAL MAINTENANCE
  • STORAGE
• 8 TROUBLESHOOTING
  • SYMPTOM(S)
• 9 SPECIFICATIONS
  • Machine overall dimensions
  • Weight from the machine
  • Capacities
  • Engine
  • Transmission
  • Power Take-Off (PTO)
  • Steering general specifications
  • Hydraulics
  • Three-point hitch
  • Brakes
  • Electrical system
  • Radio (if equipped)
• 10 ACCESSORIES
  • Rear license plate holder - Localization overview .
