Case CX460 Tier 3 Crawler Excavator Service Manual PDF

Service manual contains technical service and repair information for Case crawler excavators CX460.
This service manual includes detailed technical descriptions of Case crawler excavators, technical service information, detailed diagrams and circuits, fitting instructions,  technical specifications, special instructions, assembly instructions for Case excavators.
This manual is a detailed source of important service information for Case crawler excavators, who wants to improve the quality of their own maintenance and repair their own equipment.
This service manual comes in PDF and includes 688 pages, which are printable and readable. We recommend to use Adobe PDF Reader, to be sure all images / graphics will display correctly.

Table of Contents:

• 1 GENERAL INFORMATION
  • Safety, general information and standard torque data
  • General specifications and special torque setting
• 2 ENGINE
  • Radiator and oil-cooler
  • Engine specifications
  • Disassembly and assembly of the engine
• 3 FUEL SYSTEM
  • Fuel tank
  • Fuel engine system
• 4 ELECTRICAL SYSTEM
  • Electrical system, electrical and electronic troubleshooting
  • Main and engine electronic control boxes
• 5 UNDERCARRIAGE
  • Removal and installation of tracks
  • Rollers
  • Sprocket
  • Idler wheel and tension shock absorber
• 6 DRIVE TRAIN
  • Drive motor and final drive transmission removal and installation
  • Swing reduction gear, removal and installation
  • Swing reduction gear, disassembly and assembly
  • Travel reduction gear disassembly and assembly
• 7 UNDERCARRIAGE HYDRAULICS
• 8 UPPERSTRUCTURE HYDRAULICS
  • Depressurising and decontaminating the hydraulic system, use of the
  • vacuum pump and bleeding the components
  • Specifications, troubleshooting, checks and hydraulic pressure settings
  • Hydraulic reservoir removal and installation
  • Main and hydraulic pilot pumps, removal and installation
  • Main hydraulic control valve, removal and installation
  • Attachment cylinders, removal and installation
  • Hydraulic swivel, removal and installation
  • Pilot blocs, removal and installation
  • Swing motor, removal and installation
  • Main hydraulic pump, disassembly and assembly
  • Main hydraulic control valve, disassembly and assembly
  • Attachment cylinders, disassembly and assembly
  • Hand control levers, disassembly and assembly
  • Foot control levers, disassembly and assembly
  • Six-solenoid valves, disassembly and assembly
  • Caution valve, disassembly and assembly
  • Safety valves
  • Hydraulic swivel, disassembly and assembly
  • Swing motor, disassembly and assembly SM4608019-0EN
  • Hydraulic functions
  • Travel hydraulic motor, disassembly and assembly
  • Fan motor, removal and installation
  • Fan motor, disassembly and assembly
  • Fan pump, removal, disassembly, assembly and installation
  • Hydraulic component functions
• 9 UPPERSTRUCTURE
  • Upperstructure, turntable and counterweight
  • Boom, dipper and bucket
  • Seat, removal and installation
  • Cab and cab equipment
  • Air conditioning unit disassembly and assembly
  • Large size hydraulic schematics
  • Large size electrical schematics
