Case Combines 7230 8230 9230 Axial-Flow Set of Service Manuals

The Case company takes care of its customers in such a presented as high-quality and detailed instructions for use, repair, and maintenance, so that combines owners can always use their equipment for its intended purpose and get the maximum benefit.

These manuals describe the procedures for operating, processing, lubricating, maintaining, checking and adjusting, in one word, everything you need for comfortable use of your equipment. This manual contains charts and diagrams, special instructions, technical information, so use all this information for each maintenance and repair procedure. Before starting the equipment read the manuals, this will help to avoid damage and prolong the life of your equipment.

The manuals contained in PDF format, on English. Thanks to the PDF format it is possible to print the entire instruction or the individual diagrams and schemes. You can work with this manual after installing Adobe PDF Reader.

Models:
7230
8230
9230

Contents:
1. Engine
2. Main gearbox and drive
3. Transmission
4. Front axle system
5. Rear-axle system
6. Hydrostatic drive
7. Power Take-Off (PTO)
8. Brakes and controls
9. Hydraulic systems
10. Steering
11. Wheels
12. Tracks and track suspension
13. Cab climate control
14. Electrical systems
15. Attachments/Headers
16. Product feeding
17. Threshing
18. Separation
19. Residue handling
20. Cleaning
21. Crop storage / Unloading
