Case 2142, 2152 and 2162 Draper Header CA20 Combine Adapter Service Manual PDF

This Service Manual contains important information about the working, adjustment, and repair of your Draper Header and Combine Adapter. Refer to the Table of Contents at the beginning of this guide to locate specific items about the machine. This electronic file should be used in conjunction with the Draper Header Operator’s Manual. Also, the tutorial includes safety rules, troubleshooting, general procedures, the sections about systems(hydraulic, electrical), etc.

The case book covers a lot of necessary illustrations and diagrams, different tables and schemes which help you easily and quickly learn and understand all text. Before using this text, you should familiarize yourself with the safety rules in order to avoid injury unforeseen situations the equipment. All information is set out in an accessible language and is packaged in PDF file.  We advise you to use the application Adobe PDF Reder, which will correctly transmit all data and circuits without distortion.

Models:
 2142, 2152, 2162

Table of Contents:

1 - GENERAL INFORMATION AND SAFETY
2 - TROUBLESHOOTING
3 - GENERAL PROCEDURES
4 - KNIFE DRIVE
5 - ADAPTER DRIVE
6 - DRAPER DRIVE
7 - REEL DRIVE
8 - HYDRAULIC SYSTEM
9 - ELECTRICAL SYSTEM
10 - FLEX LINKAGE
11 - STRUCTURE
