AGCO Power WinEEM5 SERVICE TOOL v9.0 [2025]

Item Details

WinEEM5 – Service Tool (AGCO POWER EEM5 Electronic Engine Management System) v9.0 is a diagnostic and maintenance solution designed for AGCO Power engines equipped with the EEM5 control system. It allows technicians to monitor, troubleshoot, and service engine control units (ECUs) with precision and efficiency.

The tool communicates with the engine ECU via the CAN bus to read fault codes, perform tests, and analyze system parameters. Faults can be identified directly through the software, transmitted to the vehicle’s dashboard, or displayed as blink codes on a diagnostic lamp. Once a fault code is identified, the accompanying documentation helps interpret its meaning and suggest repair actions. For in-depth inspections, basic measuring tools such as a multimeter may be required.

WinEEM5 combines a professional-grade interface with extensive diagnostic functions, making it a reliable choice for workshops and service centers handling AGCO Power equipment across different regions.

Supported CAN Adapters

WinEEM5 supports several CAN interface adapters commonly used in professional diagnostic environments. These interfaces allow communication between the diagnostic software and the engine ECU over the CAN bus. Users can select the preferred adapter from the connection menu within the software.

• PCAN-USB — Widely used USB-to-CAN adapter providing stable communication and broad compatibility with EEM5 engine systems.
• AGCO 2x4 — The official AGCO adapter designed specifically for AGCO Power machinery and electronic control units. Recommended for OEM-level diagnostics and flashing.
• Vector — A professional-grade CAN interface from Vector Informatik offering high-performance communication for advanced diagnostics and testing environments.

All listed adapters are supported in WinEEM5 v9.0. Before establishing a connection, ensure the correct driver is installed and that the adapter is properly recognized by the operating system.

Release Notes v9.0

• Support for EEM5X engine control units.
• Additional measurable signals and improved value rounding in engine logs.
• Enhanced oscilloscope and recording viewer with time range configuration and recording options.
• Improved DPF monitoring — including temperature range and remaining ash service time.
• Optimized CAN/UDS communication and flashing reliability.
• Refined fault descriptions and troubleshooting guides.
• Memory and performance optimizations for smoother operation.

The version 9.0 update refines many existing features, focusing on stability, usability, and clearer diagnostic feedback. Minor interface adjustments and expanded signal options improve workflow for technicians working on EEM5-equipped engines.

Previous Version Highlights

Version 8.1 introduced J1939 support, cylinder numbering corrections for seven-cylinder engines, and multi-DTC conversion support. Interface improvements such as “My Favorites,” faster access to logs, and enhanced oscilloscope usability were also added.

Version 8.0 featured a major design refresh, adding a new main menu and a built-in oscilloscope for ECU signal measurement. It also improved recording performance, allowed customizable signal colors, and included new diagnostics for DPF and SCR systems.

Version 6.0 expanded system diagnostics with automatic engine log saving, SCR and DPF testing, emission control monitoring, injector calibration, compression tests, and fault snapshots. It also added HTML log support, actuator control, and emission fault management tools. This release laid the groundwork for the modern, feature-rich architecture that continues today.

Technical Information

• Version: 9.0
• Update Year: 2025
• Size (Installed): 300 MB
• Supported Regions: All regions
• Interface Language: English
• Supported OS: Windows 10 / Windows 11 Pro x64

Delivery (Instant Download)

After purchase, you’ll receive instant access to the installation files and documentation. The download package includes the WinEEM5 diagnostic application, release notes, and troubleshooting materials. Simply install the software on a compatible Windows PC, connect your CAN adapter, and begin diagnostics immediately.

For the best user experience, ensure your system meets the minimum requirements and that you have an active CAN communication interface compatible with AGCO Power systems.

Summary

WinEEM5 v9.0 continues to evolve as a reliable and capable service tool for AGCO Power engines. Its comprehensive diagnostic coverage, fault analysis, and streamlined updates make it essential for professionals who maintain and repair advanced electronic diesel systems. With enhanced signal monitoring, optimized performance, and improved fault handling, it delivers precision and efficiency where it matters most — in the field and in the workshop.

References

• AGCO Power Official Documentation (Service Tool Release Notes, 2025)
• SAE J1939 Communication Standard Overview – Wikipedia
