Komatsu Hydraulic Mining Shovel PC4000 Service Manuals PDF

We provide you service manuals for Komatsu Hydraulic Mining Shovel PC4000 models. Electronic material will help to identify existing and potential problems, thanks to the pictures visually familiarize yourself with every piece of your equipment, make a quality repair procedure, technical maintenance, and much more useful procedures especially for your technic. In addition, the tutorial includes chapters about safety rules, technical data, assembly procedure, components information, operation instruction, lubrication systems, preventive maintenance, general setting, step by step repair, many schemes, different diagrams with descriptions for this Komatsu Hydraulic Mining Shovel PC4000 models.

We advise you to familiarize yourself with all the sections in these factory files, especially pay attention to the section on the safety rule. An online text comes in PDF format and has 800+649 pages. For convenience, we recommend using Adobe PDF Reader to ensure the correct display of all graphics. You can ask any questions about this device, we will answer them.

MACHINE MODEL  PC4000-6 Diesel
SERIAL NUMBER 08175 /78 /79 /83 /84

MACHINE MODEL SERIAL NUMBER
PC4000-6- Electro 08165

Table of Contents:

00 Safety - Foreword
01 Technical DATA (Leaflet)
02 Assembly PROCEDURE (Brochure)

Section
1. Main assembly groups
2. Drive.
3. Hydraulic oil tank.
4. Hydraulic oil cooling.
5. Controlling.
6. Components
7. Main hydraulic pumps and pump regulation.
8. Operating hydraulic.
9. Hydraulic track tensioning system.
10. Hydraulic operated excess ladder
11. Central refilling system (Hydraulic operated refilling arm)
12. Hints for the hydraulic circuit diagram
13. Hints for the electric circuit diagram
14 VHMS
15 Lubrication Systems
